: (PGM, NAME="01")
; T1  D=6 CR=3 - ZMIN=-14 - BALL END MILL
; T2  D=9 CR=0 TAPER=118DEG - ZMIN=-51.975 - DRILL
; T3  D=16 CR=0 - ZMIN=-51.5 - FLAT END MILL
; T4  D=50 CR=0 - ZMIN=-14 - FACE MILL
; T5  D=10 CR=0 TAPER=45DEG - ZMIN=-15 - CHAMFER MILL
: G90 G40 G94
G17
G71
M26
; ADAPTIVE2
M9
M26
:T4 M6
M26
:T3
S5000 M3
H0
M8
G0 X94.223 Y86.426
Z12
Z4.51
Z0
G1 Z-5 F1000
X,Y,Z->
<-X,Y,Z
:T5 M6
M26
:T4
S5000 M3
H0
M8
G0 X12 Y-1
Z15
Z5
G1 Z1 F333
Z-2
G18 G2 X13 Z-3 I13 K-2
G1 X14 F1000
G17 G3 X15 Y0 I14 J0
X-15 I0 J0
X15 I0 J0
X14 Y1 I14 J0
G1 X13
G18 G3 X12 Z-2 I13 K-2
G0 Z5
X51.5
G1 Z1 F333
Z-2
G3 X50.5 Z-3 I50.5 K-2
G1 X49.5 F1000
G17 G3 X48.5 Y0 I49.5 J0
G2 X-48.5 I0 J0
X-34.295 Y34.295 I0 J0
X0 Y48.5 I0 J0
X48.5 Y0 I0 J0
G3 X49.5 Y-1 I49.5 J0
G1 X50.5
G18 G2 X51.5 Z-2 I50.5 K-2
G0 Z15
X1 Y-55.5
Z5
G1 Z1 F333
Z-14
G19 G3 Y-54.5 Z-15 J-54.5 K-14
G1 Y-53.5 F1000
G17 G3 X0 Y-52.5 I0 J-53.5
G1 X-50
G2 X-52.5 Y-50 I-50 J-50
G1 Y50
G2 X-50 Y52.5 I-50 J50
G1 X50
G2 X52.5 Y50 I50 J50
G1 Y-50
G2 X50 Y-52.5 I50 J-50
G1 X0
G3 X-1 Y-53.5 I0 J-53.5
G1 Y-54.5
G19 G2 Y-55.5 Z-14 J-54.5 K-14
G0 Z15
G17
M9
M26
G0 X0 Y0
M30
M2
M5
